galvanized light gauge steel framing roll forming machine with servo motor

Product Details:

Place of Origin:	Hebei
Brand Name:	JCX
Certification:	CE
Model Number:	roll forming machine

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	5000-12000
Delivery Time:	45days
Payment Terms:	L/C, T/T

Contact Now

Detailed Product Description

Use:	Roof	Color:	Blue
Certification:	CE	Warranty:	One Year
Roller:	Cr12# Steel, Cr Plated 0.05mm	PLC Brand:	Delta/Panasonic, Touch Screen
After-sales Service Provided:	Engineers Available To Service Machinery Overseas	Shaft:	50mm, 45# Steel, Forged

Product Description

Product Application

Our Automatic Light keel roll forming machine, is control by computer, Non stop tracking , fast speed can be 50m/min.

Designs can be cusotmized : C U Omegar L etc.

SPECIFICATIONS FOR Auto Steel Tile Roll Forming Machine
Decoiler	3TON manual decoiler	Optional hydraulic decoiler
Main forming machine	forming steps	10-12 stations
	rollers	Cr12,surface chrome 0.03-0.05mm, Hard chrome mirror polishing, ensure roller smooth. Spacers must lathe inner holes, and do Chrome plating;
	shafts:	50mm 45#steel,quenched
Cutting system	Cutter blade	Cr12Mov, thickness 20mm
Control system	PLC	Delta
	Transducer	xinjie
	Touch Screen	Delta
	Power	380V, 3Phase, 50Hz or as required
Run out tables	3m per set	2 sets

Main Features

1) Easy operate. full auto

2) Adopting advanced world famous brand components in electric parts operation parts.

3) High speed, non stop tracking cutting,

4) High precision, making finished sheet in good appearance

5) Long life time.

Certifications

Detailed Images

Machine Parts

Name: Decoiler

Brand:China own made

Capacity: 3tons

Main Features

Name: Feeding flate
Equipped with manual pre-cutting device to avoid waste of coil

Machine Parts

Name: Main forming system
1. Rollers adopt Cr12,surface chrome 0.03-0.05mm,
Hard chrome mirror polishing, ensure roller smooth.
Spacers must lathe inner holes, and do Chrome plating;
2. Transfer method adopts gear.

Main Features

Name: Control system
Delta touch screen, Delta frenqucy inveter

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

Packaging
Size	5.9m1.71.7m
Weight	4-10tons
Packaging Details	Main machine wrapped with film, Small spare parts put into cartons. Fixed to 20/40GP conatiner as per machines
