| Place of Origin: | China |
| Brand Name: | JCX |
| Certification: | CE |
| Model Number: | Standing Seam Roll Forming Machine |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | USD7000-USD8500 PER SET |
| Packaging Details: | Sea worthy standard package: covered with plastic film, fixed into 20/40'gp container |
| Delivery Time: | 20-30 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30 SETS PER MONTH |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Condition: | New |
|---|---|---|---|
| Cutting: | Hydraulic Cutting | Power(w): | 2.2KW |
| Warranty: | 12 Months,and Life Long Tracking Service | Dimension(l*w*h): | 2.7M* 1.4 M*1.4M |
| Weight: | 1.25T | Use: | For Making Roof Sheet |
| Voltage: | 380V 50Hz 3Phases Or As Your Requirment | Tile Type: | GI/PPGI/AL |
| Control System: | Totally Automatic PLC Taiwan Delta Or Siemens Control System | Name: | Standing Seam Roofing Roll Forming Machine |
| Product Name: | Portable Clip Lock Standing Seam Roof Roll Forming Machine | ||
| High Light: | 2.2KW Standing Seam Roll Forming Machine,Standing Seam Roll Forming Machine Galvanized |
||
Standing Seam Roll Forming Machine, Popular in USA Snap Lock Standing Seam Roof Panel Roll Former
1. Technical details of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former:
| Machine Specifications | |
| Weight | About 1.25tons |
| Size | About 2.7mx1.4mx1.4m(length x width x height) |
| Color | Main color: blue or as your requirement |
| Warning color: yellow | |
| Suitable Raw Material | |
| Material | Galvanized Steel Coils |
| Thickness | 0.3-0.8mm |
| Yield Strength | 235Mpa |
| Main Technical Parameters | |
| Quantity of forming rollers stations | 8 |
| Diameter of forming rollers shafts | 70mm |
| Roll Forming Speed | 15-20m/min |
| Forming rollers material | No.45 steel, coated with chromed treatment |
| Cutter material | CR12 mould steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 2.2kw |
| Electric voltage | According to customer’s requirement |
2. Main components of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former
| Decoiler | 1 Set |
| Guiding Equipment | 1 Set |
| Roll Forming Unit | 1 Set |
| Post Cutting Unit | 1 Set |
| Hydraulic Station | 1 Set |
| PLC Control System | 1 Set |
| Reveiving Table | 1 Set |
3. Production Flows of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former
Uncoiling the sheet---Infeed guiding--Roll forming----Measure length---Cutting the panel--panels to the supporter
4.Profile drawing of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former:
5.Description of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former:
Snap Lock Standing Seam Roof Panel Roll Forming Machinery manufactures the finest portable standing seam roof panel machine in the industry. With an easy to use and versatile line of panel machines, Snap Lock Standing Seam Roof Panel Roll Forming machines are the go to machine for the serious metal roofing contractor.
Our factory is manufacturing high quality guardrail roll forming machines, and regularly exported to Australia, USA, Thailand, Canada,Turkey, Indonesia, Philippines, Malaysia, India, Angola, etc.
7.Machine photo of Popular in USA Snap Lock Standing Seam Roof Panel Roll Former:
8. Application
This machine is widely used in the production of the roofing panel building.
9. Advantages
· Germany COPRA software design
· 5 engineers with more than 20 years experience
· 30 professional technician
· 20 sets advanced CNC production lines on site
· Passionate Team
· Installation engineers can reach your factory within 6 days
· 1.5 years maintenance and whole life technical support
10. Our service
A. Foreign debugging
If you need, we will arrange our professional engineers to help you install and debug the machines well. Buyer should pay $60 per day
B. Guarantee period
The warranty will be maintenance, maintain in the guarantee period of 18 months starting from delivery. Because of the quality of equipment during guarantee period, we will provide the parts free of charges, which is in the conditions of correct operation. (Natural disasters or factors which can’t forced by human are excluded).
C. Training
During installation and adjustment of the equipment, our engineers shall provide the training to
buyer’s personnel request to operate and maintain the equipment. Including foundation construction, electrical works, hydraulic oil, safe operation and non-standard safety items, testing material and etc.
D. Lifetime services
Life time services to every customer.
Welcome to contact with us!
Contact Person: Celina Li
Tel: +8615128751166
