Place of Origin: | China |
Brand Name: | JCX |
Certification: | CE and ISO |
Model Number: | CZ80-300 |
Minimum Order Quantity: | 1 set |
---|---|
Price: | USD30000-USD32500 PER SET |
Packaging Details: | Sea worthy standard package: covered with plastic film, fixed into 20/40'gp container |
Delivery Time: | 20-30 working days |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 30 SETS PER MONTH |
Product Name: | CZ Purlin Roll Forming Machine | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
---|---|---|---|
Voltage: | 380V 50Hz 3phases | Cutting Blade Material: | Cr12MoV |
Condition: | New | Cutting: | Hydraulic Cutting |
Name: | Full Automatic CZ Purlin Roll Forming Machine | Shaft Material: | 40Cr |
Usage: | Build The Workshop | Power(w): | 22 KW |
Warranty: | 12 Months,and Life Long Tracking Service | Dimension(l*w*h): | 10.1*1.2*1.2 |
Control System: | PLC Control System(brand As Requirement) | Tile Type: | Steel |
Weight: | 3.2T |
CZ80-300 Purlin Roll Forming Machine , Full Automatic CZ Channel Roll Forming Machine
1. Description of CZ purlin roll forming machine:
CZ purlin roll forming machine is a machine that produces C shaped or Z Purlin steel channels continuously out of galvanized or cold rolled steel strips from feeding, punching for holes, bending and cutting.
The main components of a CZ Purlin roll forming machine include a manual de-coiler (3TONs capacity), a feeding guide for materials of different sizes, a leveling device, a front hydraulic punching for holes or slots on flanges, roll forming part, a rear hydraulic punching for holes or slots on web, a hydraulic cutting for cut to length, a PLC control cabinet, and and a hydraulic oil pump.
2. Technical details of door shutter roll forming machine:
Machine Specifications | |
Weight | About 9.5tons |
Size | About 10.1*1.2*1.2m(length x width x height) |
Color | Main color: blue or as your requirement |
Warning color: yellow | |
Suitable Raw Material | |
Material | Galvanized Steel Coils |
Thickness | 1.5-3.0 mm |
Yield Strength | 235Mpa |
Main Technical Parameters | |
Quantity of forming rollers stations | 18 |
Diameter of forming rollers shafts | 60mm |
Roll Forming Speed | 15-25m/min |
Forming rollers material | No.45 steel, coated with chromed treatment |
Cutter material |
Cr12MoV steel, with quenched treatment |
Controlling system | PLC and Converter |
Electric Power requirement | Main motor power: 22kw hydraulic motor |
Electric voltage | According to customer’s requirement |
3. Main components of door shutter roll forming machine
Decoiler | 1 Set |
Guiding Equipment | 1 Set |
Roll Forming Unit | 1 Set |
Post Cutting Unit | 1 Set |
Hydraulic Station | 1 Set |
PLC Control System | 1 Set |
Reveiving Table | 1 Set |
4. Production Flows
Uncoiling the sheet---Infeed guiding--Roll forming---Rectifying the straightness---Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)
5. Advantages
· Germany COPRA software design
· 5 engineers with more than 20 years experience
· 30 professional technician
· 20 sets advanced CNC production lines on site
· Passionate Team
· Installation engineers can reach your factory within 6 days
· 1.5 years maintenance and whole life technical support
6. Application
The CZ purlin which was produced by CZ purlin roll forming machine can be used for the major stress structure of the large and middle-sized industrial constructions and civilian constructions. The roof load bearing and wall panel supporting the plants, warehouses, engine houses, hangars, exhibition halls, cinemas, gymnasiums, fair flower stands, etc.
7. Product photo
8. FAQ
1. Does one machine can only produce one style panel profile?
Not exactly.For wider and double layer making machine. It can produce more than 6 kinds of panels.
2. Do you have after sales support?
Yes, we are happy to give advice and we also have skilled technicians available across the world.We need your machines running in order to keep
your business running.
3. How to visit your company?
a.Fly to Beijing airport: By high speed train From Beijing Nan to CangZhou Xi (1 hour), then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai HongQiao to Cangzhou Xi(4.5 hours), then we can pick up you.
4. What can you do if the machine broken?
Our machine's warranty period is 24months,if the broken parts can't repair,we can send the new parts replace the broken parts freely,but you need
pay the express cost yourself.if after warranty period,we can through negotiation for to solve the problems,and we supply the technical support for
the whole life of the equipment.
5. Can you be responsible for transport?
Yes,please tell me the destination port or address.we have rich experience in transport.
6. Why your price is higher than others?
As we persist on that each factory should put quality at the first place. We spend time and money on developing how to make machines much more automatic, accurate and high quality.
