| Place of Origin: | China |
| Brand Name: | JCX |
| Certification: | CE and ISO |
| Model Number: | standing seam roll forming machine |
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | according to your profile drawing we will offer you the best price |
| Packaging Details: | this machine will be shipped by LCL shipping, the main machine and PLC and pump are covered with plastic films,the spare parts in carton. |
| Delivery Time: | 20 working days |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 30 SETS roll forming machine |
| Type: | Standing Seam Roll Forming Machine | Weight: | 3.5T |
|---|---|---|---|
| Dimension(l*w*h): | 5200*1150*1350mm | Production Capacity: | 15-25 M/min |
| Voltage: | 380V ,50HZ ,3Phase Or Request | Control System: | PLC Control System To Operate |
| Raw Material: | PPGI | Usage: | Roofing Building Use |
| Warranty: | 15 Months Guarantee Since The Buyer Receive The Mchine | Decoiler: | 5 Tons Decoiler Or Hydraulic Decoiler Can Choose |
Color Steel Panel Standing Seam Roll Forming Machine PLC Control Full Automatic
1.Application of Color Steel Panel Standing Seam Roll Forming Machine PLC Control Full Automatic:
This machine final products is the roofing panel ,we can build different size roof panel, it is very easy to operate and change size, it is very portable and easy operation Machine.
Color steel tile has the good characteristics, such as lightweight, high strength, colorful, easy installation, anti-seismic, fire-proofing, rain-proof, long service life, maintenance-free, etc. Now, it is widely popularized and used. This machine is suit for the production of various kinds of color steel tiles.
2.Main componets of Color Steel Panel Standing Seam Roll Forming Machine PLC Control Full Automatic:
| No. | Name | Unit | Qty |
| 1 | Decoiler | set | 1 |
| 2 | Main Machine for roll forming | set | 1 |
| 3 | Cutting System | set | 1 |
| 4 | Output Table | set | 1 |
| 5 | Control System(PLC) | set | 1 |
| 6 | hydraulic station | set | 1 |
3.Machine picture of Color Steel Panel Standing Seam Roll Forming Machine PLC Control Full Automatic:
4.Machine specification of Color Steel Panel Standing Seam Roll Forming Machine PLC Control Full Automatic
| Machine Specifications | |
| Weight | About 3.5tons |
| Size | About5.2*1.15*1.35m(length x width x height) |
| Color | Main color: blue or as your requirement |
| Material | PPGI |
| Thickness | 0.3-0.7 mm |
| Yield Strength | 235Mpa |
| Quantity of forming rollers stations | 16 |
| Diameter of forming rollers shafts | 60mm |
| Roll Forming Speed | 10-20m/min |
| Forming rollers material | No.45 steel, coated with chromed treatment |
| Cutter material | Cr12 steel, with quenched treatment |
| Controlling system | PLC and Converter |
| Electric Power requirement | Main motor power: 4kw |
5.Packing and loading
6.Certification
