Capacity: | 10-12m/min | Usage: | Cable Making Industry |
---|---|---|---|
Main Frame350H Steel: | 25mm Steel | Main Motor: | 5.5KW*4 |
Roller Station: | 26 Stations | Dimension(l*w*h): | 36m*3m*1.3m |
Control System: | PLC Delta | Cutting Type: | Pre-cutting Hydraulic |
Profile: | Cable Tray Roll Forming Machine | Material Width: | 100-800mm |
Highlight: | Cable Tray Roll Former 12m/Min,26 Roller Stations Cable Tray Roll Former |
High Speed 10-12m/min Steel Galvanized C Channel Cable Tray Roll Forming Making Machine
1. Description of cable tray roll forming machine:
Our cable tray roll forming machine could produce wide range of sizes, commonly used width is 100-800mm, we can also customize according to your width, and automatic change by motors from one size to the other not only at width but also at height. Change size is very simple, the step is put your required data into touch screen and wait for few seconds. And other wise innovation is that one machine could make cable trays and covers of corresponding size. Change time is only 30 minutes, it's easy to operate , this machine can save cost and save space.
Our factory is manufacturing high quality cable tray roll forming machine, and regularly exported to South Africa, Zambia, Rwanda, Dubai, Poland, Saudi Arabia, Israel, Philippines, Thailand, Canada
Because the thickness of the working material is different, the yield strength is different, and the profile profile is different, these factors affect the configuration of the machine is different, so if you want to customize a metal corrugated roof roll forming machine, please send me your profile drawing, the thickness of your material, yield strength, etc., so that our engineers can help you customize the right machine according to your requirements.
2. Technical details of cable tray roll forming machine:
Machine Specifications | |
Weight | About 10tons |
Size | About 36m*3m*1.3m(length x width x height) |
Color | Main color: blue or as your requirement |
Warning color: yellow | |
Suitable Raw Material | |
Material | Steel Coils |
Thickness | 0.8-2.5mm |
Main Technical Parameters | |
Quantity of forming rollers stations | 26 stations |
machine frame | 400H steel 26mm |
Roll Forming Speed | 10-12m/min |
Forming rollers material | 40Cr heat treatment HRC55-60, hard chrome plating on the surface |
Controlling system | PLC and Converter |
Electric Power requirement | Main motor power: 5.5KW*4 |
Electric voltage | According to customer’s requirement |
3. Main components of cable tray roll forming machine
Hydraulic Decoiler | 1 Set |
Guiding Equipment | 1 Set |
Leveling Equipment | 1 Set |
Punching part | 1 Set |
Roll Forming Unit | 2 Set |
Post Cutting Unit | 1 Set |
Hydraulic Station | 1 Set |
PLC Control System | 1 Set |
Reveiving Table | 1 Set |
4. Production Flows
Uncoiling the sheet---Infeed guiding--Roll forming---Rectifying the straightness---Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)
5. Advantages
About the company:
1. Our company has 25 years of production experience, which can guarantee the quality of the machine
2. Our company has 5 warehouses, which store raw materials separately, and will not delay delivery
3. Our company has professional after-sales service. If you don't know anything about the machine, you can find our after-sales service at any time.
About the machine:
1.CNC machine to produce the machine rollers, which can guarantee the quality of the machine wheels
2. The large frame is produced by our company and will not be deformed
3.Chain use 1.5 inch
6. Application
This machine is widely used in the production of the cable tray line.
7. Product photo
8. FAQ
Q:What will you do if the machine broken?
A:We provide 12 months free warranty and free technical support for the whole life of any machine.
If the broken parts can’t repair,we can send the new parts replace the broken parts freely.If it is beyond the warranty period,we can negotiable to solve theproblem,and we supply the technical support for the whole life of the machine.
Q. What's your payment terms and delivery time?
A: 30% as the deposit by T/T in advance, 70% as the balance payment by T/T after your inspect the machine well and before delivery. Of course your payment terms are acceptable. After we get down payment, we will arrange production. About 30-45 days for delivery.
Contact Person: Audrey Xing
