galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase

Product Details:

Place of Origin:	China
Brand Name:	JCX
Model Number:	Floor Decking Roll Forming Machine

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD8000-USD12500 PER SET
Packaging Details:	Sea worthy standard package: covered with plastic film, fixed into 20/40'gp container
Delivery Time:	20-30 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	30 SETS PER MONTH

Contact Now

Detailed Product Description

Certification:	ISO9001 CE	Product Name:	Floor Decking Roll Forming Machine
After Warranty Service:	Line Support	After-sales Service Provided:	Video Technical Support
Warranty:	12 Months,and Life Long Tracking Service	Advantage:	Automatic Operation
Color:	Client's Request	Control Box Language:	Add Customer Request Language
Control System:	PLC(detla) System	Export Port:	Tianjin Port
Need Container:	1*40 Feet
High Light:	Floor Deck Forming Machine 380V , Floor Deck Forming Machine 50Hz

JCX High Quality Metal Steel Floor Deck Roof Roll Forming Machine Manufacturer With Best Price

1. Floor decking roll forming machine

The metal steel floor deck produced by floor decking roll forming line has high strength with big wave length. It adheres well to concrete. Used on high building, it not only saves steel mold plate, but also reduces the weight of storey. With the same bearing capacity, it economized steel and cuts down investment accordingly.
We can also supply the customized machines

2. Technical details of floor decking roll forming machine

Suitable Material	Colored or galvanized steel coil, HRB60 or equivalent
Thickness Range	0.8-1.5 mm
Coil Width Range	1000 or 1250 mm. According to your actual drawing.
Electric Power	380V, 50 Hz, 3 phase or according to your need.
Dimension	About 12.81.71.2 m(LWH), as per the drawing
Cutting	Automatically stop and cutting when it comes to the set length.
Length of the Sheet	You can set the length according to your need. It is controlled by PLC length accuracy: ±1mm.

3. Main components of floor decking roll forming machine

No.	Name	Unit	Qty
1	Decoiler	set	1
2	Entry Beach	set	1
3	Main Machine for roll forming	set	1
4	Cutting System	set	1
5	Output Table	set	1
6	Control System(PLC)	set	1
7	hydraulic station	set	1

4. Production Flows

Uncoiling the sheet---Infeed guiding--Roll forming---Rectifying the straightness---Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)

galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase 0

5. Advantages

· Germany COPRA software design

· 5 engineers with more than 20 years experience

· 30 professional technician

· 20 sets advanced CNC production lines on site

· Passionate Team

· Installation engineers can reach your factory within 6 days

· 1.5 years maintenance and whole life technical support

6. Application

The advantage of glazed steel sheet includes beautiful, classical appearance and grace taste. It is widely used in village, hotel, exhibition, vacation village, family construction and outdoor decorating.

galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase 1

7. Product photo

galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase 2

galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase 3

galvanized steel coil Floor Deck Forming Machine 380V 50Hz 3 phase 4
