Building Material Double Layer Roll Forming Machine PLC Control

Product Details:

Place of Origin:	China
Brand Name:	JCX
Certification:	CE ISO9001
Model Number:	Double layer Roll Forming Machine

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	USD8000-USD12500 PER SET
Packaging Details:	Sea worthy standard package: covered with plastic film, fixed into 20/40'gp container
Delivery Time:	20-30 working days
Payment Terms:	L/C, T/T, Western Union
Supply Ability:	30 SETS PER MONTH

Contact Now

Detailed Product Description

Product Name:	Double Layer Roofing Tile Roll Forming Machine	After-sales Service Provided:	24 Hours Video Technical Support
Machine Warranty:	12 Months And Life Long Tracking Service	Machine Color:	Client's Request
Control Box Language:	English Or Add Customer Request Language	Control System:	PLC(detla) System Or As Customer Request
Export Port:	Tianjin Port Or Other Chinese Port	Need Container:	1*40 Feet Container
Highlight:	Building Material Double Layer Roll Forming Machine , Double Layer Roll Forming Machine PLC

Building Material Roofing Sheet Roll Forming Machine Double Deck 0.3-0.8mm Thickness

1. Double layer roll forming machine

Double layer roll forming machine can roll forming two different types of roofing sheets without changing anything tools. Because double layer roll forming machine has two layers.

Upper and lower can roll-forming different sheets. Besides, the sea freight for import is saved by 50%. double layer roll forming machine is the popular and wise choice for both new entrepreneurs and established metal building manufacturers

This design of the double layer roll forming machine could increase your productivity and save space, and save the costs. The machine max roll speed can reach to 45m/min. This is very popular abroad due to its high efficiency. It can work automatically.

2. Features of Double Layer Roof Roll Forming Machine

1). Double layer roll forming machines can use a galvanized steel sheet, colored armor plate or aluminum plate as the material plate.
2). Controlling by computer, PLC display, the operation is easy, running is steady and reliable, endurable, and maintenance-free.
3). We can make and design all kinds of forming machines according to the customer's request.

3. Technical details of double layer roll forming machine

1	Coil Width	1220mm max
2	Rolling Speed	10-16m/min
3	Thickness	0.3-0.8mm
4	Control System	PLC (Panasonic)
5	Uncoiler	Manual uncoiler
6	Pre-cutting	Pre-cutting install after feeding for customer change coil only
7	Roller Stations	Up layer: 24stations Down layer: 22 stations
8	Roller Material	45# steel with chrome plated surface
9	Shaft Material	Dia 76mm, material:45#, quenching and tempering, coated with hard chrome
10	Post cutting	The machine adopts hydraulic cutting system
11	Material Of Cutting	Cr12 steel, 58-62 HRC
12	Maim Motor Power	11 KW
13	Hydraulic Station Power	7.5 KW
14	Hydraulic Pressure	12-16Mpa adjustable
15	Structure Of The Stations	Guide pillar
16	Tolerance	3m+-1.5mm
17	Voltage	380V, 50HZ,3 phase
18	Drive Method	By gear chain

4. Main components of double layer roll forming machine

Double layer roll forming machine
Name	Quantity	Units
5T manual uncoiler (Hydraulic uncoiler)	1	Set
Adjustable feeding platform	1	Set
Roll forming system	1	Set
Plc cut to length	1	Set
Hydraulic system	1	Set
Delta Electronic Control System	1	Set
Supporter/Automatic Stacker	1	Set

5. Production Flows

Uncoiling the sheet---Infeed guiding--Roll forming---Rectifying the straightness---Measure length---Cutting the panel--panels to the supporter (option: automatic stacker)

Building Material Double Layer Roll Forming Machine PLC Control 0

6. Advantages

· Germany COPRA software design

· 5 engineers with more than 20 years experience

· 30 professional technician

· 20 sets advanced CNC production lines on site

· Passionate Team

· Installation engineers can reach your factory within 6 days

· 1.5 years maintenance and whole life technical support

7. Application

The advantage of glazed steel sheet includes beautiful, classical appearance and grace taste. It is widely used in village, hotel, exhibition, vacation village, family construction and outdoor decorating.

Building Material Double Layer Roll Forming Machine PLC Control 1

8. Product photo

Building Material Double Layer Roll Forming Machine PLC Control 2

Building Material Double Layer Roll Forming Machine PLC Control 3

9. FAQ

1. who are we?
We are based in Hebie, China, start from 2010,sell to Africa(20.00%),Domestic Market(20.00%),Southeast Asia(15.00%),South America(10.00%),North America(5.00%),Eastern Europe(5.00%),Oceania(5.00%),Mid East(5.00%),Central America(5.00%),South Asia(5.00%),Eastern Asia(2.00%),Western Europe(2.00%),Southern Europe(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Roof Sheet Roll Forming Machine,Wall Panel Roll Forming Machine,Highway Guardrail Plate Forming Machine,Floor Decking Sheet Rolling Machine,C Purlin Making Machine

4. why should you buy from us not from other suppliers?
1.Rich experience 2.High-quality after-sales service system 3.Brand and Qualification Guarantee 4.Technological innovation advantage

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
